Deskripsi

Ports

48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex:10BASE-T/100BASE-TX: half or full;

1000BASE-T: full only

Additional Ports

1 RJ-45 console port to access limited CLI port

Memory & Processor

MIPS @ 650 MHz, 32 MB flash, 128 MB SDRAM; packet buffer size: 512 KB 1.5 MB

Mounting and enclosure

Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware

included), wall mount

Performance

100 Mb Latency : < 7 s

1000 Mb Latency : < 5 s

Throughput : up to 71.4 Mpps (64-byte packets)

Switching capacity : 96 Gbps

MAC address table size : 16384 entries

Environment

Operating temperature : 32F to 104F (0C to 40C)

Operating relative humidity : 5% to 95%, noncondensing

Non operating/Storage temperature : -40F to 158F (-40C to 70C)

Non operating/Storage relative humidity : 5% to 95%, noncondensing

Altitude : up to 16,404 ft (5 km)

Acoustic : Power: 49.7 dB, Pressure: 49.7 dB; ISO 7779

General Protocols

IEEE 802.3az Energy Efficient Ethernet

IEEE 802.3i 10BASE-T

IEEE 802.3x Flow Control
