Deskripsi

Ports

8 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u

Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type: Auto-MDIX;

Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only Supports a maximum of 8 autosensing 10/100/1000 ports

Mounting

Desktop (rear port)

Memory and processor

Packet buffer size: 187.5 KB

Latency

100 Mb Latency: < 3 s (LIFO 64-byte packets)

1000 Mb Latency: < 2,6 s (LIFO 64-byte packets)

Throughput

up to 11.8 million pps

Routing/switching capacity

16 Gbps

MAC address table size

4096 Entries

General protocols

IEEE 802.1p Priority; IEEE 802.3az Energy Efficient Ethernet; IEEE 802.3x Flow Control

Power and operating requirements

Input voltage

100-240 VAC

Input frequency

50/60 Hz

Safety

UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1-03

Electromagnetic compatibility

EN 55022 Class B; ICES-003 Class B; FCC Part 15, Class B; AS/NZS CISPR22 Class B

Operating temperature range

0 to 40C

Operating humidity range

15 to 95% (noncondensing)

Acoustic pressure emissions

Fanless
