The 10G Smart Switches provide comprehensive L2+/Layer 3 Lite features in order to meet current and future needs on virtualization, converged networking and mobility.
The XS748T is also ideal for smaller workgroups that need high bandwidth for sharing, collaborating, editing, and publishing high-density content like video or animation.
– 10-Gigabit copper ports: 44 10GBASE-T copper
– SFP ports: 4 SFP+ 1000/10GBASE-X fiber ports (shared)
– Buffer size: 3 MB
– MAC address data-base size: 16K
– VLAN (# supported): 512
– Number of LAGs & number of members: 24 LAGS with max 8 members in each LAG (LACP)
– Number of priority queues: 8
– Access Control Lists (ACLs): 164 shared for MAC, IP and IPv6 ACLs
– IPv4 Static routes: 64
– IPV6 Static routes: 64
– Power supply: Internal 100-240VAC 50-60Hz
– Max power consumption (Watts): 262.8 W
– VLAN routing: Yes
– Dynamic VLAN assignment: Yes
– MLD Snooping: Yes
– Static route: Yes (32)
– Host ARP table: 512 ARP
– EEE: Yes
– DoS Prevention: Yes
– Internal/External: External DC 54V 1.25A
– Max consumption (Watts): 15.1W
– FAN: 4
– Acoustic Noise Level @25C (dBA): 47.8 dBA
– Operating Temperature: 0° to 50°C (32° to 122°F)
– MTBF (@ 25° C): 483,808 hours
– Electromagnetic compliance (A or B): Class A
