HARDWARE FEATURES
Interface 4 10/100/1000Mbps RJ45 Ports
1 RJ11 Port
1 USB 2.0 Port
Button 1 Power On/Off Button
1 WPS Button
1 Wi-Fi On/Off Switch
1 RESET Button
Dimensions (W X D X H) 8.9×5.5×1.3 in.(225x140x32.5mm)
External Power Supply 12VDC/1.5A
IEEE Standards IEEE 802.3, 802.3u, 802.3ab
ADSL Standards Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite)
ITU-T G.994.1 (G.hs)
ITU-T G.995.1
ADSL2 Standards ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.4(G.lite.bis)
ADSL2+ Standards ITU-T G.992.5
Antenna Type Omni directional, Detachable, Reverse SMA
Antenna Gain 2 x 5dBi
WIRELESS FEATURES
Wireless Standards IEEE 802.11b, 802.11g, 802.11n
Frequency 2.400-2.4835GHz
Transmit Power 20dBm (EIRP)
Wireless Security Support 64/128 bit WEP, WPA /WPA2, WPA-PSK/WPA2-PSK
Wireless MAC Filtering
SOFTWARE FEATURES
Quality of Service WMM, Bandwidth Control (IP QoS)
Security NAT Firewall, SPI Firewall, MAC / IP / URL Filtering
IPv6 IPv6 and IPv4 dual stack
Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4
Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6
Management Web Based Configuration(HTTP)
Remote management
Telnet management
Command Line Interface
SSL for TR-069
SNMP V1/V2C
Web Based Firmware Upgrade
CWMP(TR-069)
Port Forwarding Virtual server, Port Triggering, UPnP, DMZ, Manage Control
VPN Pass-Through PPTP, L2TP, IPSec Pass-through
ATM/PPP Protocols ATM Forum UNI3.1/4.0
PPP over ATM (RFC 2364)
PPP over Ethernet (RFC2516)
IPoA (RFC1577/2225)
PVC – Up to 8 PVCs
Advanced Features Guest Network, Parental Control, Wireless Schedule
Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt
Dynamic Host Configuration Protocol (DHCP), DHCP relay
Network Address
